Specifications
| Paramerters | |
|---|---|
| Model | 2024 or 2023 or 2025 |
| Type of energy | Diesel |
| Operating weight | 12.35 t | 27218 lb |
| Bucket capacity | 0,21 m³ |
| Travel speed | 1.7-2.9 mi/h |
| Swing speed | 9.5 tr/min |
| Bucket digging force | 10004 lbf |
| Arm digging force | 5462.9 lbf |
| Maximum digging height - long arm | 5.77 m | 18,93' |
| Maximum digging reach - long arm | 6.32 m | 20.73' |
| Overall width | 5 340 mm (17'6") |
| Total height | 2.55 m | 8.37' |
| Maximum right swing working width | 2.13 m | 6.99' |
| General | |
|---|---|
| Warranty | 3 y / 3 600 h |
| Engine | |
|---|---|
| Engine model | Kubota/V2403/Niveau 4F |
| Rated power/speed | 41.2 HP |
| Rated power | 30.7 kW |
| Driving | |
|---|---|
| Displacement | 0.6 gal |
| Couplers | |
|---|---|
| Maximum torque/speed | 1500 tr/min |
